Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 48697 |
| Body Style | Rectangular |
| Connection Type | QD Integral |
| Current, Switching | 100 mA |
| Housing Material | Zinc Alloy Die-Cast |
| Humidity | 90% @ 50 C |
| Indicator | LEDs |
| Input Output | Discrete |
| IP Rating | IP67 |
| Light Source | Visible Red LED |
| Maximum Operating Temperature | 55 C |
| Measurement Range | 0.15 m |
| Mechanical Angle | 1 |
| Minimum Operating Temperature | -20 C |
| Mounting Type | Threaded |
| NEMA Rating | NEMA 6 |
| Number of Pins | 4 |
| Operating Temperature, Maximum | 55 C |
| Operating Temperature, Minimum | -20 C |
| Operation | Dark-ON/Light-ON |
| Output | PNP |
| Response Time | 1 ms |
| Sensing Mode | Background Suppression Adjustable |
| Series | |
| Supply Voltage | 10-30 VDC |
| Technology | Photoelectric |
| Time, Turn-On Delay | 100 ms |
| Type | Reflective Sensors |
Overview
QM42/QMT42 Series
The Turck Banner QM42/QMT42 series of photoelectric sensors feature compact, low-cost dc sensors in NEMA 6 (IEC IP67) die-cast housings and deliver outstanding immunity to electrical noise. The QMT42 series is slightly larger than the QM42 series and offers the longest range of any diffuse sensor on the market (6 m).
