Name: Banner Engineering S18AW3FF100
SKU: 781965

Product Details ＋

Product Attribute	Attribute Value
Alternate Mfr Part Number	30328
Body Style	Cylindrical
Cable Length	2 m
Connection Type	Cable
Current, Leakage	100 μA
Current, Switching	300 mA
Diameter, Body	18
Housing Material	Thermoplastic
Humidity	90% @ 50 C
Indicator	LEDs
Input Output	Solid-State AC Switch
IP Rating	IP67
Light Source	Infrared LED
Material, Lens	Acrylic
Maximum Operating Temperature	70 C
Measurement Range	0.1 m
Mechanical Angle	16
Minimum Operating Temperature	-40 C
Mounting Type	M18 Threaded
NEMA Rating	NEMA 6P
Number of Pins	3
Operating Temperature, Maximum	70 C
Operating Temperature, Minimum	-40 C
Output	SPST
Output Current	300 mA (Max.)
Repeatability	4 ms
Response Time	16 ms
Sensing Mode	Background Suppression Fixed
Sensing Range	100
Series
Standards	CE Marked, CSA Certified, UL Listed
Supply Voltage	20-250 VAC
Technology	Photoelectric
Time, Turn-On Delay	100 ms
Type	Reflective Sensors

Overview

Photoelectric Sensor, Thermoplastic Polyester Housing Material, 90% @ 50 °C (Max.) Humidity

The EZ-BEAM® represents a technological breakthrough in photoelectric sensors design, making sensing applications less complicated and sensors easier to use. Most models have no adjustments as the specially designed fixed-field diffuse and polarized retroreflective optics provide reliable sensing, without need for sensitivity or background suppression adjustments.

Features

EZ-BEAM® Sensors Are Low-Cost, Yet Offer Powerful Sensing Performance

EZ-BEAM® Circuitry Is Completely Epoxy-Encapsulated to Provide Superior Durability, Even in Harsh Environments

EZ-BEAM® Sensor Selection Is Simply a Matter of Choosing a Sensor Housing Style, Operating Voltage, and Sensing Mode

Specifications

18 mm Thermoplastic Threaded Barrel Housing Rated NEMA 6P (IEC IP67)

Operating Temperature: -40°C to 70°C, 90% Relative Humidity @ 50°C (Non-Condensing)

Response Time: 3 Milliseconds "On", 1.5 Milliseconds "Off"
